Color
Color
Color
Applications
- Municipal waste water
- Industrial waste water
- Rivers and surface water
- Drinking water
- Monitoring process liquids
- Measurement of water quality for distribution or discharge
Description
Online analyzer for the determination of the intensity of color of acqueous streams.
Method
The method is based on the photometric determination of the color intensity.. The light radiation that passes through the sample water is absorbed and the absorption is proportional to the color intensity. The measurement is expressed in Hazen scale (platinum-cobalt scale).
Features
| Measured parameter | Color | ||
|
Range
|
|||
| Demineralized water | Not required |
| Min. analysis time | 1 minutes |
Reagents and standards
- No reagents required.
- See standard solutions for Color analyzer.
Technical Specifications
| Model | 3S-UVCOLOR |
| Sampling Mode | Batch, with freely settable frequency. |
| Sample | Pressure: Atmospheric Temperature: 5 ‐ 45°C (41 ‐ 113°F) Flow Rate: 80 to 500 mL/min Connection: 6 mm (¼-in.) |
| Drain |
Pressure-free drain Connection: 12 mm (½-in.) |
| Input Streams | 2 |
| Material | Epoxy-coated stainless steel AISI 304 |
| Dimensions (H x W x D) | 604 x 380 x 210 mm (23.6 x 14.8 x 8.2 in) |
| Weight | 20 kg (44 lbs) |
| Power Supply |
Input Voltage: 115 VAC,230 VAC Power consumption: max. 80 W |
| Output signals |
2 x 4-20 mA analog outputs Modbus via RS485,Ethernet |
| Alarms | 2 SPDT programmable voltage-free relays |
| Digital Input | None, Online, Start Extra, Skip Idle, Emergency Stop |
| Ambient Temperature | 5 - 45 °C (41 - 113 °F) |
| Ambient Humidity | 10 - 90 % RH (non-condensing) |
| Protection Grade | IP54 (indoor only, outdoor use possible with external cabinet, not included) |
